Thermoplastic paint making plant
Short Description
Aimax Ride-On Thermoplastic Road Marking Machines are built for contractors who need consistent output, durability, and flexibility in different project conditions. These machines deliver precise line marking with controlled thickness and excellent bonding on road surfaces. With multiple capacity options, advanced heating systems, and now electric drive variants, they are suitable for everything from municipal jobs to large highway contracts.
Description
Model Series: Aimax Road Master ARM1000 | ARM1500 | Aimax Line Rider 200 | Aimax Line Rider 300
Aimax Road Master and Line Rider series are designed with real site conditions in mind. Whether it is a highway project or city road maintenance, these machines offer reliable performance with minimal downtime.
The machines are powered either by a diesel engine (approx. 10 HP) or an electric drive system, giving contractors flexibility depending on site conditions. Electric variants are especially useful in urban zones, tunnels, and projects where noise and emissions are a concern.
The thermoplastic material is heated using two system options:
- Commercial LPG + Oil Jacket Heating System
- Diesel Burner + Oil Jacket Heating System
For continuous operation, machines can be paired with high-capacity pre-heater tanks (500 Kg to 1000+1000 Kg), ensuring uninterrupted workflow.
The marking system includes a hydraulic agitator, pneumatic screed shoe, and automatic glass bead dispenser, delivering high-quality, reflective, and long-lasting road markings.
Thermoplastic Pre-Heater Options
| Model Type | Capacity | Description |
| Single Tank | 500 Kg | Suitable for small to medium jobs |
| Twin Tank | 500 + 500 Kg | Balanced continuous operation |
| Heavy Duty Twin Tank | 1000 + 1000 Kg | High production highway projects |
Heating Options Available:
- LPG + Oil Jacket Heating System
- Diesel Burner + Oil Jacket Heating System
Key Features
- Self-Propelled Ride-On Machine for continuous operation
- Available in Diesel Drive and Electric Drive Models
- Compatible with 500 Kg to 2000 Kg Pre-Heater Systems
- LPG + Oil Heating and Diesel Burner Heating Options
- Precision Screed Shoe for sharp and uniform lines
- Automatic Glass Bead System for reflective markings
- Computerized Skip Line Control for accurate dash marking
Specification
Parameter Line Rider 200 Line Rider 300 ARM1000 ARM1500 Line Rider 200E (Electric) Line Rider 300E (Electric) ARM1000E (Electric) ARM1500E (Electric)
Machine Type Ride-On Ride-On Ride-On Automatic Ride-On Automatic Ride-On Electric Ride-On Electric Ride-On Electric Automatic Ride-On Electric Automatic
Drive System Diesel Engine Diesel Engine Diesel Engine Diesel Engine Electric Motor Drive Electric Motor Drive Electric Motor Drive Electric Motor Drive
Engine / Motor 10 HP Diesel 10 HP Diesel 10 HP Diesel 10 HP Diesel High Torque Electric Motor High Torque Electric Motor High Torque Electric Motor High Torque Electric Motor
Tank Capacity 200 Kg 300 Kg 300 Kg 500 Kg 200 Kg 300 Kg 300 Kg 500 Kg
Heating System LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner LPG / Diesel Burner
Heating Type Oil Jacket Oil Jacket Oil Jacket Oil Jacket Oil Jacket Oil Jacket Oil Jacket Oil Jacket
Drive Speed 0–8 km/hr 0–8 km/hr 0–10 km/hr 0–10 km/hr 0–6 km/hr 0–6 km/hr 0–8 km/hr 0–8 km/hr
Marking Speed 0–2 km/hr 0–2 km/hr 0–2 km/hr 0–2 km/hr 0–2 km/hr 0–2 km/hr 0–2 km/hr 0–2 km/hr
Stirrer System Hydraulic Hydraulic Hydraulic Hydraulic Electric / Hydraulic Electric / Hydraulic Electric / Hydraulic Electric / Hydraulic
Screed Shoe Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic Pneumatic
Shoe Sizes 100–300 mm 100–300 mm 100–300 mm 100–300 mm 100–300 mm 100–300 mm 100–300 mm 100–300 mm
Glass Bead System Drop-On Drop-On Drop-On Drop-On Drop-On Drop-On Drop-On Drop-On
Bead Tank ~100 Kg ~100 Kg ~100 Kg ~100 Kg ~100 Kg ~100 Kg ~100 Kg ~100 Kg
Control System Manual / Semi Auto Semi Auto Fully Automatic Fully Automatic Semi Auto Semi Auto Fully Automatic Fully Automatic
Skip Line Device Optional Optional Automatic Automatic Optional Optional Automatic Automatic
Steering Manual Manual Manual Manual Electric Assist Electric Assist Electric Assist Electric Assist
Standard Config
Standard Configuration
- Screed Shoe (100 mm & 150 mm Standard)
- Automatic Glass Bead Dispenser
- Hydraulic Stirrer System
- Operator Seat & Control Panel
Features
- Flexible Power Options
Available in both diesel and electric drive models to suit different working environments. - Continuous Working Capability
Supports large pre-heater tanks to ensure uninterrupted operation in highway projects. - High Precision Output
Screed shoe and automatic control system ensure uniform, sharp, and durable markings.
FAQ
ARM1500 and ARM1500E are ideal for heavy-duty highway work. Yes, both heating options are available depending on requirement. For continuous large projects, yes—it significantly improves productivity. 500 Kg for small, 500+500 Kg for medium, 1000+1000 Kg for heavy projects. Yes, with automatic skip line controller. 100 mm to 300 mm standard. Yes, automatic drop-on system is provided. Yes, with proper pre-heater support. Basic training is recommended. Asphalt and concrete surfaces. Yes, as per country and project requirements. Which model is best for highways?
Can I use both LPG and diesel heating?
Is pre-heater necessary?
What capacity pre-heater should I choose?
Does it support dashed line marking?
What is the marking width range?
Is glass bead system included?
Can machine run full day continuously?
Is operator training required?
What type of roads can it work on?
Can it be customized for export?
