Bitumen Pressure Distributor
The Bitumen Pressure Distributor is an essential machine for modern road construction, designed to ensure accurate and uniform spraying of bitumen across the road surface. Built for reliability and consistent performance, it plays a critical role in asphalt road construction, surface dressing, and maintenance works.
Engineered for contractors, government projects, and infrastructure developers, this machine delivers controlled spraying, reduces material wastage, and improves overall road quality.
With multiple capacity options and advanced control systems, it is suitable for both small-scale and large highway projects.
Description
Working Principle
The Bitumen Pressure Distributor heats and maintains the bitumen at the required temperature inside an insulated tank. A high-performance pump circulates the bitumen through pipelines and spray nozzles.
During operation, the spray bar distributes bitumen evenly across the road surface. The pressure system ensures uniform flow, while adjustable nozzles control spray width and pattern. Operators can control flow rate, pressure, and spray width either from the cabin or rear platform, depending on configuration.
Applications
- Prime coat and tack coat spraying
- Asphalt road construction projects
- Surface dressing works
- Highway and rural road development
- Road repair and maintenance operations
Advantages
- Ensures uniform bitumen distribution for stronger road bonding
- Reduces material wastage and operational costs
- Improves road life and surface quality
- Easy operation with flexible control options
- Suitable for varied project sizes and site condition
Specification
Specification 6000 Ltr Model 8000 Ltr Model 10000 Ltr Model 12000 Ltr Model
Tank Capacity 6000 Litres 8000 Litres 10000 Litres 12000 Litres
Mounting Type Truck Mounted Truck Mounted Truck Mounted Truck Mounted
Heating System Burner Heating (Diesel / LPG) Burner Heating (Diesel / LPG) Burner Heating (Diesel / LPG) Burner Heating (Diesel / LPG)
Insulation Glass Wool / Rock Wool Glass Wool / Rock Wool Glass Wool / Rock Wool Glass Wool / Rock Wool
Bitumen Pump Type Gear Pump Gear Pump Gear Pump Gear Pump
Spray Bar Width Adjustable (Left / Right / Middle Operation) Adjustable (Left / Right / Middle Operation) Adjustable (Left / Right / Middle Operation) Adjustable (Left / Right / Middle Operation)
Spray Control Manual / Optional Solenoid Control/ Pneumatic Cylinder Manual / Optional Solenoid Control/ Pneumatic Cylinder Manual / Optional Solenoid Control/ Pneumatic Cylinder Manual / Optional Solenoid Control/ Pneumatic Cylinder
Operation Control Cabin / Rear Control Cabin / Rear Control Cabin / Rear Control Cabin / Rear Control
Spray Bar Folding Hydraulic / Manual Folding Hydraulic / Manual Folding Hydraulic / Manual Folding Hydraulic / Manual Folding
Nozzle Type Precision Spray Nozzles Precision Spray Nozzles Precision Spray Nozzles Precision Spray Nozzles
Optional System HMI Display, Solenoid Valve System HMI Display, Solenoid Valve System HMI Display, Solenoid Valve System HMI Display, Solenoid Valve System
Operator Platform Available (Rear Control Models) Available (Rear Control Models) Available (Rear Control Models) Available (Rear Control Models)
Standard Config
Features
Key Features
- Uniform Bitumen Spraying System
- Dual Operation Control (Cabin / Rear Side)
- Adjustable Spray Bar (Left – Right – Middle Operation)
- Foldable Spray Bar (Left & Right Side)
- Solenoid Valve Controlled Spray System (Optional)
- Optional HMI Display in Cabin
- Rear Operator Platform with Seat
FAQ
Standard models include 6000 Ltr, 8000 Ltr, 10000 Ltr, and 12000 Ltr. Yes, it can be operated from both the cabin and rear control platform. The spray bar can be adjusted left, right, or fully opened depending on road width. It provides precise control over spray pattern and reduces bitumen wastage. Yes, it can be folded from both sides for easy transport and safety. Diesel or LPG burner heating systems are used to maintain bitumen temperature. Yes, rear control models include an operator platform with a seat. It allows easy monitoring and control of machine functions from the cabin. Yes, it is suitable for both small roads and large highway construction projects. Yes, precise control systems ensure efficient usage of material. Yes, optional features and configurations can be provided based on project requirements. What capacity options are available?
Can the machine be operated from the truck cabin?
How is spray width controlled?
What is the benefit of the solenoid valve system?
Is the spray bar foldable?
What type of heating system is used?
Is an operator seat provided?
What is the advantage of an HMI display?
Can it be used for highway projects?
Does it reduce bitumen wastage?
Is the machine customizable?
Related products
Asphalt Batch Mix Plant
Asphalt Batch Mix Plant (80 TPH – 320 TPH)
Aimax Asphalt Batch Mix Plants are engineered for precision and reliability, offering a wide capacity range from 80 TPH to 320 TPH to suit every contractor’s production needs. From the cost-efficient Smart Series for small projects to the high-output Titan Series for mega-infrastructure, our plants provide future-ready, fuel-efficient asphalt production solutions.
Key Features
- High Performance: Consistent and uniform asphalt mix quality with fast batch cycles.
- Fuel Efficiency: Optimized burners and heat transfer systems reduce fuel consumption per ton.
- Advanced Automation: PLC-based systems ensure accurate weighing and real-time monitoring.
- Modular Design: Built for easy transport, fast installation, and seamless future upgrades.
- RAP Compatibility: Designed to support up to 40% Reclaimed Asphalt Pavement (RAP) integration.
Asphalt Drum Mix Plant
Aimax Asphalt Drum Mix Plant is a high-performance continuous asphalt mixing solution designed for modern road construction projects.
It ensures consistent output, fuel efficiency, and superior asphalt quality with advanced drum mixing technology.
Engineered for durability and precision, it delivers reliable performance in all working conditions.
Ideal for contractors seeking cost-effective and high productivity asphalt production.
Key Features
- Continuous type drum mixing technology for uninterrupted production
- Fuel-efficient burner system reducing operational costs
- Advanced SCADA/PLC control system with HMI interface
- Accurate electronic belt weighing system with load cell
- Heavy-duty dryer drum with triple heat transfer mechanism
- Uniform asphalt coating with optimized mixing flights
- Low maintenance design with high durability components
- Environment-friendly pollution control unit
Automatic Road Marking Machine
Aimax Ride-On Thermoplastic Road Marking Machines are built for contractors who need consistent output, durability, and flexibility in different project conditions. These machines deliver precise line marking with controlled thickness and excellent bonding on road surfaces. With multiple capacity options, advanced heating systems, and now electric drive variants, they are suitable for everything from municipal jobs to large highway contracts.
Bitumen Drum Decanter
